It is a lightweight mobile gold mining equipment for individuals and small cooperatives, integrating screening, washing, gold separation and tailing discharge.
With compact volume, flexible movement and no need for fixed foundation, it can start working immediately after landing and is suitable for mountainous areas and narrow sites.
Equipped with a vibrating chute, the recovery rate of fine gold and flake gold is stable, and it can be operated by a single person with simple one-key start.
The small trommel screen gold washing machine is a lightweight and low-cost mobile gold mining equipment specially designed for individuals and small cooperatives. It adopts a small trommel screening structure as the core, integrates simple sand washing and separation functions, and is driven by a small motor (diesel power optional) to realize the separation of sand ore and impurities and sand gold recovery. The equipment has the advantages of compact volume, light weight, convenient transfer, simple operation, low energy consumption, low maintenance cost, wear resistance, anti-silting, anti-blocking and strong adaptability. No professional technology and fixed site are needed, and the operation can be completed by 1-2 people. It is the first choice for personal gold panning and sand gold recovery in small scattered mining sites, taking into account practicality and economy.
Core Parameters
Model
Trommel Specification (D×L) mm
Processing Capacity (t/h)
Trommel Speed (r/min)
Total Power (kW)
Gold Recovery Rate (%)
Overall Dimension (L×W×H) mm
Movement Mode
XDT-600 (Mini)
Φ600×2000
5-15
28-35
5.5 (22HP diesel optional)
≥88
5000×1800×2200
Small tire traction (manual assisted)
XDT-800 (Small)
Φ800×2500
15-30
25-32
11 (30HP diesel optional)
≥90
6500×2200×2600
Small tire traction (for agricultural tractor)
XDT-1000 (Small)
Φ1000×3000
30-50
22-28
18.5 (40HP diesel optional)
≥91
7500×2500×2800
Small tire traction / manual moving
Product Advantages & Technical Highlights
Compact & Flexible: Small volume, light weight, easy traction, suitable for mountainous and narrow sites
Lower Investment: Economical cost, fast cost recovery, ideal for individuals and small mining sites
Integrated Design: Integrates screening, ore washing, gold separation and tailing discharge in one unit
No Foundation Needed: Start working immediately after landing, no cement foundation, simple installation
Easy Operation: One-key start, operable by a single person, labor-saving
High Recovery Rate: Equipped with vibrating chute, stable recovery of fine gold and flake gold
Applicable Scenarios & Materials
Applicable Scenarios
Small placer gold mines, scattered mountain mining sites, river and beach gold panning
Dry land small-scale gold separation, tailings reprocessing, personal mobile gold panning operations
Applicable Materials
Placer gold ore, river sand ore, mountain sand ore, weathered sand, fine gold, flake gold, granular gold
