Mining Trommel Screen – Professional Ore Screening Equipment
The mining trommel screen is a professional integrated equipment for ore screening and washing, specially developed for mining working conditions with heavy load resistance and stable and reliable screening.
It features large processing capacity, anti-blocking material, simple maintenance and strong versatility, suitable for screening various mining materials such as sand gold and tailings.
The equipment supports mobile operation and fixed installation, and is the core pre-treatment equipment to improve the beneficiation efficiency of sand gold and iron ore mining areas.
The mining trommel screen is a professional integrated equipment for ore screening and washing designed for ore pre-treatment. It adopts a reinforced and wear-resistant structure, which can efficiently complete ore classification, impurity removal and mud washing, and solve the material blocking problem of high mud content ore. The equipment supports mobile operation, adapts to a variety of beneficiation production lines, and is the core pre-treatment equipment to improve the beneficiation efficiency of sand gold, iron ore and other mining areas.
Core Parameters & Specifications
Model
Drum Size (Length × Diameter) mm
Processing Capacity (m³/h)
Screen Mesh Aperture (mm)
Total Motor Power (kW)
Equipment Weight (kg)
Installation Method
KGS-10 Small
2000×800
8-15
5-20
5.5
1200-1500
Tire Traction Mobile
KGS-20 Standard
3000×1000
15-25
5-25
7.5
2200-2600
Tire Traction Mobile
KGS-30 Medium
4000×1200
25-35
5-30
11
3500-4000
Semi-trailer Traction Mobile
KGS-50 Large
5000×1500
40-50
5-30
15
6000-6500
Semi-trailer Traction Mobile
KGS-80 Double Layer
6000×1800
60-80
Upper:10-30 / Lower:5-15
22
9500-10000
Fixed / Semi-trailer Mobile
Product Advantages & Technical Highlights
Special for mining: Designed for mining working conditions, heavy load resistant, stable and reliable screening
Large processing capacity: Continuous rotary screening, suitable for mass material processing in mines
Durable: Thickened and reinforced frame, impact and fatigue resistance, long service life
Anti-blocking: Trommel screening, smooth feeding of wet, sticky and soil-containing materials
Easy maintenance: Simple structure, few wearing parts, convenient later inspection and replacement
Strong versatility: Applicable to various mining materials such as sand, ore sand, tailings, gold ore
Applicable Scenarios & Materials
Applicable Scenarios
Primary screening of placer gold ore
Mine tailings treatment
Sand and gravel aggregate classification
Soil and rock separation in stone yard
Sand making production line
River sand mining and screening
Mine raw material pre-treatment
Desliming of muddy ore materials
Applicable Materials
Placer gold ore, river sand, mountain sand, weathered sand
Ore mixture, soil and rock mixture, tailings sand
Sand and gravel aggregate, muddy sand and gravel, loose gravel, silty clay
