The economic double-deck circular vibrating screen is a cost-effective grading and screening equipment, driven by a side-mounted eccentric block exciter to make the screen body perform circular motion vibration. It is equipped with a double-deck screening structure, with a metal woven screen mesh on the upper layer and a receiving trough on the lower layer, mainly for the grading and screening of sand stone, ore and other materials. The equipment has a compact structure and stable operation, suitable for small sand and stone factories, concentrators and other scenarios. It can complete two-stage grading at one time, with the advantages of controllable cost and convenient maintenance.
Product Specification
Model
Screen Surface Size (L×W) mm
Processing Capacity (t/h)
Excitation Frequency (r/min)
Motor Power (kW)
Equipment Weight (t)
YJ1224
1200×2400
30-80
750-900
7.5
2.2-2.6
YJ1530
1500×3000
50-120
750-900
11
3.5-4.0
YJ1836
1800×3600
80-200
750-900
15
5.2-5.8
Product Advantages
Compact structure: Double-deck grading design, small floor space and high efficiency
Wear-resistant material: Metal woven screen mesh, high impact resistance and long service life
Stable operation: Spring shock absorption structure, low vibration noise
