The belt conveyor is a core material transfer equipment for various production lines, adopting wear-resistant rubber belt + integrated forming frame, focusing on the continuous, stable and efficient conveying of block, granular, sand and stone materials without complicated installation. It can seamlessly connect with feeders, crushers, sand making machines, silos and other front and rear end equipment. The equipment is suitable for various indoor and outdoor working conditions, with the advantages of stable conveying, wear resistance, and flexible convenience. The conveying length and speed can be adjusted on demand, covering the material transfer needs of small, medium and large production lines, and it is an essential basic equipment for the smooth flow of materials in production lines.
Core Parameter Specification
Model
Processing Capacity (t/h)
Belt Width (mm)
Climbing Angle (°)
Motor Power (kW)
Conveying Length (m)
Equipment Weight (t)
Max Feeding Particle Size (mm)
KP-800
100-200
800
0-30
7.5-15
10-30
3.5-5.0
≤300
KP-1000
200-350
1000
0-35
15-30
10-50
6.0-8.5
≤400
KP-1200
350-500
1200
0-40
30-45
15-60
9.5-12.0
≤500
KP-1600
500-800
1600
0-45
45-75
15-80
15.0-18.5
≤600
Product Advantages & Technical Highlights
Stable Conveying: Anti-deviation and anti-material falling design, no spilling or loss during material transfer
Wear Resistant & Durable: Thickened wear-resistant belt + anti-corrosion idler, wear and corrosion resistant for long-term outdoor use
High-efficiency Transfer: Continuous uninterrupted conveying, greatly improving the material turnover efficiency of production lines
Flexible Adaptation: Customizable conveying length and width, suitable for various front and rear end production equipment
Easy to Install & Maintain: Modular assembly, convenient installation and commissioning, simple daily maintenance, labor saving
Applicable Scenarios & Materials
Sand Gold Mining Production Line: Horizontal/short-distance transfer of sand gold ore raw materials and sorted materials, docking with vibrating screens and gold panning equipment
Sand and Stone Production Line: Transfer of raw materials such as pebbles and granite and finished sand, connecting with feeders, crushers and silos
Mine Beneficiation Production Line: Continuous transfer of ore, tailings and finished ore, docking with beneficiation, crushing and screening equipment
Infrastructure/Solid Waste Treatment: Transfer of construction waste, engineering aggregate and crushed stone, suitable for various infrastructure and solid waste recycling production lines
